While most households are still going to be fine with Gigabit Ethernet, as broadband speeds climb and local devices start needing more LAN performance, it’s clear the time for faster wired networking in your home is coming sooner rather than later.
The next step-up is 2.5GbE, and you’d think it would be a simple case of just buying a new router and network interface cards, but thanks to some industry fumbles, 2.5GbE isn’t as simple as it should have been.
2.5GbE was supposed to be the easy Ethernet upgrade
Double or nothing?
The sales pitch for 2.5GbE is about as simple as it gets. Most people don’t need, and will likely never need, 10Gbps Ethernet. These technologies were designed for business customers, and the equipment you need to install this fast networking technology in your home is expensive.
A 2.5Gbps connection kicks the can far down the road, so it’s a safe upgrade to make in terms of headroom. 2.5GbE technology works with your existing Cat5e or Cat6 cables, so you don’t have to lay new wires. That’s perfect for modern developed countries where 1Gbps internet connections are becoming more common. It’s becoming common for new motherboards, routers, and NAS devices to have at least one 2.5GbE port.
The thing is, just because a device you buy has a 2.5GbE logo on it, doesn’t mean it’s going to work. The IEEE 802.3bz standard is perfectly fine on paper, but years of inconsistent hardware, buggy firmware, immature drivers, and compatibility issues have left many people wondering why their expensive new network still only connects at 1Gbps or even disconnects altogether.
The transition from NBASE-T to the IEEE standard left some lasting scars
Not exactly a clean move
One of the big reasons there are some issues with 2.5Gbps network hardware today, is that the creation of the final standard was a little messy. Before 802.3bz was finalized, the NBASE-T Alliance was formed to help build it. The idea was to create faster than 1Gbps networking using existing cabling.
However, some hardware shipped before the standard was finalized, and despite 802.3bz officially being compatible with earlier NBASE-T hardware, in practice issues cropped up. As our friends at XDA point out, certain network chipsets are notorious for being unreliable with 2.5GbE. These issues aren’t that widespread, but it does cause plenty of edge cases. Since network gear like switches and routers have long working lifespans, and might not get updated diligently, you could easily run into issues yourself.
If you buy older gear or used gear to integrate into your existing 2.5GbE setup, you might find it just doesn’t want to play ball at the advertised speeds or at all. So get ready for firmware updates, or messing with network card drivers until you throw your hands up in the air and just go out and buy a new network card, switch, or router.
- Manufacturer
-
UniFi
- Type
-
Managed Ethernet Switch
The Unifi Flex Mini 2.5G Ethernet Switch is a fully-managed network switch delivering multi-gig speeds. It works both standalone or with a Unifi Network Controller, making it a versatile option for your network setup. You get an included USB-C power adapter, though the switch can be powered over PoE+ from the upstream switch.
Auto-negotiation is where many problems begin
Hidden behind mediocrity
The truly ironic part is that if you’re getting disconnections or other errors when you try to set up your 2.5GbE network, that might actually be a better outcome. At least then you know something’s not right and you can do something about it.
A more insidious outcome is when you plug in the cables, turn on the gear, and everything works fine. Except, if you took the time to test the link speed you’d see you were only getting 1Gbps. That’s because during the handshake where the two 2.5GbE devices negotiate a speed, something went wrong and 1Gbps is the safe fallback.
The reason you might not notice is that in most cases you probably weren’t even saturating 1Gbps of bandwidth, and none of the services you use benefit from the additional speed. Netflix won’t look any better, because it maxes out at around 25Mbps for a 4K stream, as one example.
The problem is if you were upgrading to 2.5GbE in order to get some future-proofing for high-speed fiber, or a new NAS you plan to buy at some point, then you’ve got a bit of a time bomb. You’ll only realize you’ve paid 2.5Gbps money for a 1Gbps line down the road and now have to try and manually get that high-speed connection going.
The technology isn’t broken—but buyers need to know what they’re connecting
The truth is that, overall, 2.5GbE is generally reliable and works as advertised, but there are enough teething troubles, and enough low-quality or early-generation hardware around that it can sour the experience.
The good news is that you probably don’t have to worry about this for some time, and hopefully, by the time you really can’t get along with 1Gbps Ethernet anymore, the situation will have gone from “pretty OK” to “basically bulletproof.” That day is not yet today, so you need to do a little more research before buying that switch or router, but five minutes on Google is a small price to pay when it could save you hours of frustration.
